Catalina Yachts 22
Masthead Sloop · Swing Keel · First built 1969
A swing-keel masthead sloop with 15,000 units sold, offering a highly versatile and trailerable coastal cruiser
Designed by Frank V. Butler.
- LOA
- Beam
- Draft (max)
- Displacement
- Ballast
- Hull type
- Swing Keel
See her sail
The Catalina Yachts 22, on the water
The fleet's own footage — the truest look at how she really moves.
Footage from BoatworksToday
Is it for you?
Character
Where this design lands on the numbers a shopper trusts — read straight from her own ratios.
TrailerableBeam 2.34 m — inside the 2.55 m no-permit tow width across most of Europe, and the 2.59 m US and Canadian limit. About 1,021 kg of hull, so roughly 1,600 kg on a trailer: check that against your own towing rating.Ramp-launchableAbout 1,021 kg of hull, with a keel that raises or a draft shallow enough to float off a trailer — she can go back on the trailer at the ramp, not only into the water.Shoal draftDraws 0.61 m, board up where she has one — creeks, sandbars and thin anchorages most keels have to stay out of.
LivelyComfort 11Sea-kindly
CoastalCapsize 2.34Bluewater
LightD/L 139Heavy
EasygoingSA/D 19.1Powered-up
TenderBallast 24%Stiff
Light and lively — happiest day-sailing and coastal-hopping in settled weather.
The living fleet
Sailed by the fleet
Where the fleet has filmed this boat.
Seen once across one channel of the fleet.
The record
Full specifications
The complete reference set — tap any figure to switch between metric and imperial.
Dimensions
Weights
Ballast / displacement
24.4%
Rig & sail area
Rig
Masthead Sloop
Ratios
SA / displacement
19.1
Displacement / length
139.1
Comfort ratio
11.1
Capsize screening
2.34
Hull speed
5.9 kn
Pounds / inch immersion
530
Hull
Hull type
Swing Keel
Construction
Fiberglass
Production
Years built
First built 1969
Units built
15000
Designer
Frank V. Butler
Builder
Catalina Yachts
Boats like this, on the water
More boats like her, on the water
Comparable boats the fleet has on camera: same type, within a quarter of her length. Open the boat, or watch the video — a timestamp means she only appears in passing.
Marshall Marine Corporation Sanderling5.54 mSame hull family1.7 m shorterA gaff-rigged catboat based on a 1941 design, featuring a shallow-draft keel-centerboard hull for versatile day sailing
Dufour Yachts T66.15 mSame hull family1.1 m shorterA lightweight 800kg fractional sloop with a high sail-area-to-displacement ratio for spirited performance in light air
Este 247.50 mSame hull family0.2 m longerA lightweight 7.5-metre fractional sloop with a lifting keel, designed by German Frers for high-performance sailing
Macgregor 26X7.87 mSame hull family0.6 m longerA water-ballasted sail-power hybrid designed for versatile coastal cruising and easy trailering
Cal Boats 247.43 mSame hull family0.2 m longerThe inaugural Jensen Marine Cal model, this fractional keel-centerboard sloop was built for shoal-water versatility
The family
Related models
The designs closest to hers — usually the rest of the builder's range, sometimes the same hull sold under another name.
Catalina Yachts 22 MKIIAn upgraded 1995 iteration of the classic trailerable cruiser, featuring a fin keel and transom-hung rudderCatalina Yachts 25A 7.6-metre fin-keel sloop produced for fifteen years, offering a stable, high-volume platform for coastal cruisingCatalina Yachts Capri 22A Gary Mull-designed fractional sloop with a high sail-area-to-displacement ratio for spirited club racingCatalina Yachts 30One of the most successful production yachts in history, with over 6,000 hulls built during a 32-year runCatalina Yachts 27A masthead sloop with 6,662 hulls produced over two decades, serving as a staple of coastal cruising since 1971
