BoatsTripp 47

Tripp 47

Fractional Sloop · Fin w/bulb & Spade Rudder · First built 1992

A powerful 14.33-meter fractional sloop with a 26.3 SA/displacement ratio and a deep 2.74-meter fin keel

Designed by William H. Tripp Jr & III, built by Carroll Marine.

LOA
Beam
Draft (max)
Displacement
Ballast
Hull type
Fin w/bulb & Spade Rudder

See her sail

The Tripp 47, on the water

The fleet's own footage — the truest look at how she really moves.

Footage from Sail Libra

Is it for you?

Character

Where this design lands on the numbers a shopper trusts — read straight from her own ratios.

LivelySea-kindly

Her light displacement on a narrow beam gives 22 — a moderate, middle-of-the-road motion.

Comfort ratio 22
CoastalBluewater

2.06 — right around the 2.0 line, the edge between coastal and offshore.

Capsize screening 2.06
LightHeavy

145 — light for her waterline, so she is easily driven and quick to accelerate.

Displacement / length 145
EasygoingPowered-up

26.3 — a lot of sail for her weight; powered-up and eager, a real performer.

Sail area / displacement 26.3
TenderStiff

51% of her weight is ballast — very stiff, carrying full sail in a blow.

Ballast 51%

Light and lively — happiest day-sailing and coastal-hopping in settled weather.

  • Draws more than ~97% of boats her size on file

Compared with 2108 boats of the same type within a quarter of her length.

What the fleet has seen

The Tripp 47, as the fleet has seen it

Derived from the videos the fleet has analysed of this model. ▶ marks open the moment aboard.

The Tripp 47 is a fractional sloop sailboat designed by William H. Tripp Jr., III, and built by Carroll Marine from 1992 to the present. It features a fin keel with a bulb and a spade rudder, measures 14.3 meters LOA, has a 4.2-meter beam, a 2.7-meter draft, and displaces 8527 kg. Aboard *Sail Libra*, the crew deploys the jib by falling off the wind 10 degrees, with one person managing the furling line, a second operating the winch, and a third tailing the line to prevent tangles and ensure smooth unfurling. *Sail Libra* completed a coastal passage from Key West to Pensacola, Florida, managing spinnaker trim and experiencing a minor mainsail issue after a course adjustment.watch While some sources, like *Be The Captain*, caution that former race boats like the Tripp 47 may suffer from structural stress or delamination, they are also noted for their performance.17:21

The living fleet

Sailed by the fleet

Where the fleet has filmed this boat.

Seen 3 times across one channel of the fleet.

Basemap © Wikimedia Commons · CC BY-SA 4.0

On the water

The Tripp 47 on video

The record

Full specifications

The complete reference set — tap any figure to switch between metric and imperial.

Dimensions
Weights
Ballast / displacement
50.5%
Rig & sail area
Rig
Fractional Sloop
Ratios
SA / displacement
26.3
Displacement / length
145.1
Comfort ratio
21.7
Capsize screening
2.06
Hull speed
8.3 kn
Pounds / inch immersion
1889
Hull
Hull type
Fin w/bulb & spade rudder
Construction
Fiberglass
Ballast type
Lead
Production
Years built
First built 1992
Designer
William H. Tripp Jr, III
Builder
Carroll Marine
