What this video covers

Converting a European-built boat to a US 120-volt AC electrical system requires a complete rewire of the shore power inlet, the main panel, and all branch circuits.2:28 European systems operate at 240 volts, allowing for smaller conductor gauges due to lower amperage requirements for a given power load.1:25 US systems operate at 120 volts, which doubles the amperage for the same power output, necessitating significantly heavier copper wiring to prevent overheating and voltage drop.1:06 Retrofitting an existing vessel often requires removing cabinetry to access and replace undersized wiring throughout the boat.2:20 While some manufacturers offer US-spec wiring during initial construction for a modest cost increase, a post-build conversion is labor-intensive and expensive.2:10 Conversely, bringing a US-wired boat to Europe is straightforward, as the existing wiring is oversized for the higher voltage and only requires swapping out electrical outlets.2:41 Proper conductor sizing remains the primary constraint when importing vessels between different voltage standards.
