BoatsArcona 400

Arcona 400

Fractional Sloop · Fin Keel w/bulb · First built 2001

A 12-meter performance cruiser with a deep 2.4-meter bulb keel and a high sail-area-to-displacement ratio.

Designed by Stefan Qviberg, built by Boo Marin.

LOA
Beam
Draft (max)
Displacement
Ballast
Hull type
Fin Keel w/bulb

See her sail

The Arcona 400, on the water

The fleet's own footage — the truest look at how she really moves.

Footage from SEILmagasinet

Is it for you?

Character

Where this design lands on the numbers a shopper trusts — read straight from her own ratios.

LivelySea-kindly

Her light displacement on a moderate beam gives 23 — a moderate, middle-of-the-road motion.

Comfort ratio 23
CoastalBluewater

2.02 — right around the 2.0 line, the edge between coastal and offshore.

Capsize screening 2.02
LightHeavy

169 — light for her waterline, so she is easily driven and quick to accelerate.

Displacement / length 169
EasygoingPowered-up

21.2 — plenty of sail for her weight; lively and quick to respond.

Sail area / displacement 21.2
TenderStiff

39% of her weight is ballast — moderately stiff, a middle-of-the-road stability.

Ballast 39%

Light and lively — happiest day-sailing and coastal-hopping in settled weather.

  • Draws more than ~95% of boats her size on file

Compared with 2888 boats of the same type within a quarter of her length.

What the fleet has seen

The Arcona 400, as the fleet has seen it

Derived from the videos the fleet has analysed of this model. ▶ marks open the moment aboard.

The Arcona 400 is a 12.0 m fractional sloop designed by Stefan Qviberg and built by Boo Marin / Arcona Yachts since 2001. It features a fin keel with a bulb, a 3.8 m beam, a 2.4 m draft, and a displacement of 6999 kg. The model has a reported shallow draft option of 2.0 m. An Arcona 400 competed in the Færder regatta, finishing behind a Hallberg-Rassy 342 and a Columbie 66 in its class.1:32

The living fleet

Sailed by the fleet

Where the fleet has filmed this boat.

Basemap © Wikimedia Commons · CC BY-SA 4.0

The record

Full specifications

The complete reference set — tap any figure to switch between metric and imperial.

Dimensions
Weights
Ballast / displacement
38.6%
Rig & sail area
Rig
Fractional Sloop
Ratios
SA / displacement
21.2
Displacement / length
168.5
Comfort ratio
22.9
Capsize screening
2.02
Hull speed
7.9 kn
Pounds / inch immersion
1542
Hull
Hull type
Fin Keel w/bulb
Construction
Fiberglass
Ballast type
Lead
Production
Years built
First built 2001
Designer
Stefan Qviberg
Builder
Boo Marin, Arcona Yachts (Boo Marin AB)
