Santana 20

Fractional Sloop · Fin keel, spade rudder · First built 1976

A high-performance fractional sloop with a 1996 deck redesign that added an open transom and a roomier cockpit

LOA
Beam
Draft (max)
Displacement
Ballast
Hull type
Fin w/spade Rudder

See her sail

The Santana 20, on the water

The fleet's own footage — the truest look at how she really moves.

Footage from Vela Sin Rumbo

Is it for you?

Character

Where this design lands on the numbers a shopper trusts — read straight from her own ratios.

TrailerableBeam 2.44 m — inside the 2.55 m no-permit tow width across most of Europe, and the 2.59 m US and Canadian limit. About 612 kg of hull, so roughly 1,200 kg on a trailer: check that against your own towing rating.
LivelySea-kindly

Her light displacement on a beamy beam gives 8 — a quick, lively motion that feels every wave.

Comfort ratio 8
CoastalBluewater

At 2.90 she sits above the 2.0 line — beamy for her weight, and happiest coastal.

Capsize screening 2.90
LightHeavy

147 — light for her waterline, so she is easily driven and quick to accelerate.

Displacement / length 147
EasygoingPowered-up

24.4 — a lot of sail for her weight; powered-up and eager, a real performer.

Sail area / displacement 24.4
TenderStiff

41% of her weight is ballast — moderately stiff, a middle-of-the-road stability.

Ballast 41%

Light and lively — happiest day-sailing and coastal-hopping in settled weather.

  • Lighter than ~90% of boats her size on file

Compared with 601 boats of the same type within a quarter of her length.

What the fleet has seen

The Santana 20, as the fleet has seen it

Derived from the videos the fleet has analysed of this model. ▶ marks open the moment aboard.

The Santana 20 is a 6.2-meter fractional sloop designed by W. Shad Turner and built by W. D. Schock Corp. since 1976. It features a fin keel with a spade rudder, a 2.4-meter beam, a 1.2-meter draft, and displaces 612 kg. In 1996, W.D. Schock Corp redesigned the deck, introducing an open transom and a roomier cockpit while maintaining the boat's performance characteristics.10:05 Aboard *Vela Sin Rumbo*, Fer and Renán sold their Santana 20 racing sailboat to fund a circumnavigation aboard a Catalina Morgan 45.10:02

The living fleet

Sailed by the fleet

Where the fleet has filmed this boat.

Seen once across one channel of the fleet.

Basemap © Wikimedia Commons · CC BY-SA 4.0

What they go for

Market signal

Where the fleet has seen this model come up for sale.

1seen sold

From the fleet's own footage — our observed signal, not broker listings.

The record

Full specifications

The complete reference set — tap any figure to switch between metric and imperial.

Dimensions
Weights
Ballast / displacement
40.7%
Rig & sail area
Rig
Fractional Sloop
Ratios
SA / displacement
24.4
Displacement / length
147.1
Comfort ratio
7.6
Capsize screening
2.90
Hull speed
5.4 kn
Pounds / inch immersion
457
Hull
Hull type
Fin w/spade rudder
Construction
Fiberglass
Ballast type
Lead
Production
Years built
First built 1976
Units built
900
Designer
W. Shad Turner
Builder
W. D. Schock Corp, Schock W.D
