BoatsJ Boats Tillotson Pearson J/46

J Boats Tillotson Pearson J/46

Masthead Sloop · Fin w/bulb & Spade Rudder · 1995–2003

A masthead sloop designed for offshore cruising, featuring a 1.89m draft and a balanced 10,886kg displacement

Designed by Rodney S. Johnstone & Rod Johnstone.

LOA
Beam
Draft (max)
Displacement
Ballast
Hull type
Fin w/bulb & Spade Rudder

See her sail

The J Boats Tillotson Pearson J/46, on the water

The fleet's own footage — the truest look at how she really moves.

Footage from Sailing Sweet Ruca

Is it for you?

Character

Where this design lands on the numbers a shopper trusts — read straight from her own ratios.

LivelySea-kindly

Her light displacement on a moderate beam gives 27 — a moderate, middle-of-the-road motion.

Comfort ratio 27
CoastalBluewater

1.92 — just under the 2.0 offshore line; her beam is modest for her weight.

Capsize screening 1.92
LightHeavy

161 — light for her waterline, so she is easily driven and quick to accelerate.

Displacement / length 161
EasygoingPowered-up

19.7 — plenty of sail for her weight; lively and quick to respond.

Sail area / displacement 19.7
TenderStiff

39% of her weight is ballast — moderately stiff, a middle-of-the-road stability.

Ballast 39%

Light and lively — happiest day-sailing and coastal-hopping in settled weather.

  • Beamier than ~77% of boats her size on file

Compared with 2238 boats of the same type within a quarter of her length.

What the fleet has seen

The J Boats Tillotson Pearson J/46, as the fleet has seen it

Derived from the videos the fleet has analysed of this model. ▶ marks open the moment aboard.

The J Boats Tillotson Pearson J/46 is a 14.0-meter masthead sloop designed by Rodney S. Johnstone and built by J Boats Tillotson Pearson from 1995 to 2003. With a fin keel, bulb, and spade rudder, the J/46 displaces 10886 kg. Aboard *Sailing Sweet Ruca*, the J/46 has completed extensive passages, including a 1,200-mile journey through the Patagonian fjords and an 1,800-mile transit from American Samoa to the Marshall Islands.1:09 The crew of *Sweet Ruca* performed a significant refit in Puerto Montt, Chile, replacing mainsail battens, upgrading to a 2:1 mainsail halyard, and re-bedding chain plates due to corrosion.10:57 They relocated refrigeration compressors to reduce cabin heat and reconfigured reefing lines to lead all three reefs and the vang to the cockpit.17:50 During a passage from Maine to Nantucket, *Sweet Ruca* maintained 6 to 7 knots in 10 knots of wind and reached 10.6 knots under spinnaker in 14 to 15 knots of breeze.1:41 The crew has experimented with a wing-on-wing configuration using only the jib and staysail for downwind passages in rolly seas, as seen during a three-day transit from Amanu to Tahiti.8:38 Navigating remote atolls like Amanu in the Tuamotus requires careful attention to dense coral bommies and strong currents in narrow passes.11:16 The J/46 has also sailed to Rongelap Atoll in the Marshall Islands, an area affected by radioactive fallout.0:46

The living fleet

Sailed by the fleet

The channels sailing this model, and where they were last seen.

Seen 6 times across one channel of the fleet.

Basemap © Wikimedia Commons · CC BY-SA 4.0

On the water

The J Boats Tillotson Pearson J/46 on video

Crossing the DATE Line and the EQUATOR! Epic Sailing Journey In The Remote Pacific! [Ep. 173]The J46 Sweet Ruca crosses the equator and International Date Line while sailing to the Marshall Islands.Sailing Sweet RucaThe DREAM! Sailing to TAHITI! [Ep. 159]Sweet Ruca sails wing-on-wing with dual headsails on a three-day passage from Amanu to Tahiti.Sailing Sweet RucaLife in The Tuamotus Most Remote Atolls! [Ep. 158]Navigating the coral-filled lagoon of Amanu requires careful chain management to avoid fouling on underwater bommies.Sailing Sweet RucaHuge Sailing Adventure: Cape Horn to Real-Time - Refitting Our Dream Sailboat in Patagonia [Ep. 144]The crew of *Sweet Ruca* refitted their J-46 in Puerto Montt, Chile, addressing rig, engine, and electrical systems.Sailing Sweet RucaHello Sailor! [Ep. 7]The J46 Sweet Ruca sails from Maine to Nantucket, encountering humpback whales and strong tidal currents.Sailing Sweet RucaSailing Cape Horn on a Catamaran? [Ep. 113]A Dazcat 52 performance catamaran rounds Cape Horn after a two-day passage from Puerto Williams, Chile.Sailing Sweet Ruca

What broke, what changed

Gear aboard, as the crews told it

Moments from individual boats of this model that the fleet has filmed — one crew, one piece of kit, one day on the water. Not a review of the class, and not a count of anything.

Each line is one crew's account of their own boat. Another J Boats Tillotson Pearson J/46 may be fitted out entirely differently.

The record

Full specifications

The complete reference set — tap any figure to switch between metric and imperial.

Dimensions
Weights
Ballast / displacement
39.2%
Rig & sail area
Rig
Masthead Sloop
Ratios
SA / displacement
19.7
Displacement / length
161.3
Comfort ratio
26.7
Capsize screening
1.92
Hull speed
8.5 kn
Pounds / inch immersion
1997
Hull
Hull type
Fin w/bulb & spade rudder
Construction
Fiberglass
Ballast type
Lead
Production
Years built
1995–2003
Units built
35
Designer
Rodney S. Johnstone, Rod Johnstone
Builder
J Boats Tillotson Pearson
