BoatsCal Boats 24

Cal Boats 24

Fractional Sloop · Keel/centreboard · 1958–1965

The inaugural Jensen Marine Cal model, this fractional keel-centerboard sloop was built for shoal-water versatility

Designed by C. William Lapworth, built by Jensen Marine.

LOA
Beam
Draft (max)
Displacement
Ballast
Hull type
Keel/Cbrd.

See her sail

The Cal Boats 24, on the water

The fleet's own footage — the truest look at how she really moves.

Footage from Sailing Magic Carpet

Is it for you?

Character

Where this design lands on the numbers a shopper trusts — read straight from her own ratios.

TrailerableBeam 2.44 m — inside the 2.55 m no-permit tow width across most of Europe, and the 2.59 m US and Canadian limit. About 1,361 kg of hull, so roughly 1,950 kg on a trailer: check that against your own towing rating.Shoal draftDraws 0.76 m, board up where she has one — creeks, sandbars and thin anchorages most keels have to stay out of.
LivelyComfort 14Sea-kindly
CoastalCapsize 2.22Bluewater
LightD/L 166Heavy
EasygoingSA/D 20.1Powered-up
TenderBallast 33%Stiff

Light and lively — happiest day-sailing and coastal-hopping in settled weather.

The living fleet

Sailed by the fleet

Where the fleet has filmed this boat.

Seen once across one channel of the fleet.

Basemap © Wikimedia Commons · CC BY-SA 4.0

What broke, what changed

Gear aboard, as the crews told it

Moments from individual boats of this model that the fleet has filmed — one crew, one piece of kit, one day on the water. Not a review of the class, and not a count of anything.

Each line is one crew's account of their own boat. Another Cal Boats 24 may be fitted out entirely differently.

The record

Full specifications

The complete reference set — tap any figure to switch between metric and imperial.

Dimensions
Weights
Ballast / displacement
33.3%
Rig & sail area
Rig
Fractional Sloop
Ratios
SA / displacement
20.1
Displacement / length
166.2
Comfort ratio
13.6
Capsize screening
2.22
Hull speed
6.0 kn
Pounds / inch immersion
573
Hull
Hull type
Keel/Cbrd.
Construction
Fiberglass
Ballast type
Mixed Iron/Lead
Production
Years built
1958–1965
Units built
184
Designer
C. William Lapworth
Builder
Jensen Marine, Cal Boats
