BoatsChrysler Marine 22

Chrysler Marine 22

Masthead Sloop · Swing Keel · 1975–1978

A 6.7-metre masthead sloop produced as the C-22 and T-22 Sandpiper, featuring a swing keel for shallow-water access

Designed by Halsey C. Herreshoff.

LOA
Beam
Draft (max)
Displacement
Ballast
Hull type
Swing Keel

See her sail

The Chrysler Marine 22, on the water

The fleet's own footage — the truest look at how she really moves.

Footage from Lady K Sailing

Is it for you?

Character

Where this design lands on the numbers a shopper trusts — read straight from her own ratios.

TrailerableBeam 2.36 m — inside the 2.55 m no-permit tow width across most of Europe, and the 2.59 m US and Canadian limit. About 1,361 kg of hull, so roughly 1,950 kg on a trailer: check that against your own towing rating.Shoal draftDraws 0.59 m, board up where she has one — creeks, sandbars and thin anchorages most keels have to stay out of.
LivelySea-kindly

Her moderate displacement on a beamy beam gives 15 — a quick, lively motion that feels every wave.

Comfort ratio 15
CoastalBluewater

2.15 — right around the 2.0 line, the edge between coastal and offshore.

Capsize screening 2.15
LightHeavy

195 — moderately heavy for her waterline, a balanced cruising weight.

Displacement / length 195
EasygoingPowered-up

16.2 — moderate power for her weight; steady, all-round performance.

Sail area / displacement 16.2
TenderStiff

28% of her weight is ballast — on the tender side; she'll heel readily and want a reef sooner.

Ballast 28%

A balanced, easily-driven cruiser — comfortable and forgiving for coastal work.

What the fleet has seen

The Chrysler Marine 22, as the fleet has seen it

Derived from the videos the fleet has analysed of this model. ▶ marks open the moment aboard.

The Chrysler Marine 22 is a 6.7-meter Masthead Sloop with a Swing Keel, designed by Halsey C. Herreshoff and built by Chrysler Marine from 1975 to 1978. It displaces 1360 kg and has a 2.4-meter beam and a 1.4-meter draft. Originally produced by TMI as the C-22, it was later renamed the T-22 Sandpiper, and a fixed keel model was also available.

The living fleet

Sailed by the fleet

Where the fleet has filmed this boat.

Seen 56 times across one channel of the fleet.

Basemap © Wikimedia Commons · CC BY-SA 4.0

On the water

The Chrysler Marine 22 on video

STOP! You Don’t Need to Sail Around the World!Match your boat choice to your actual cruising plans, whether island hopping or crossing an ocean.Lady K SailingHUGE Sailboat for Young Couple! Beneteau 440 and the SailblazersA young couple prepares their 1995 Beneteau Oceanis 440 for a circumnavigation after purchasing it on Facebook Marketplace.Lady K SailingDon’t Live on a Sailboat Until You Hear ThisLiving aboard requires managing marine toilets, refrigeration, and condensation, which are rarely depicted in online sailing content.Lady K SailingWhy Most People Never Live Their Sailing DreamPrioritize safety-critical repairs over cosmetic issues to stop delaying sailing plans and start gaining real experience.Lady K SailingWhy Are Used Sailboats So Cheap in 2026?Used sailboat sales in North America dropped 14% in 2025 as buyers prioritize well-maintained, documented vessels.Lady K SailingYou NEED to Keep Your Boat Receipts. Here’s WhyDigitizing maintenance records and equipment receipts in Vesselbook creates a verifiable history that increases boat resale value.Lady K SailingAre Catamarans a Waste of Money? | Hot Take TuesdayLady K compares the utility of performance catamarans like Outremer against large, amenity-heavy cruising multihulls.Lady K SailingThe Boating Industry Is About to Change!Lady K and Nate launch Vesselbook, a free crowd-sourced database rating marine businesses by HIN-linked boat records.Lady K SailingTrue Crime Sailing - A Cruising Wife Vanishes in the BahamasLynette Hooker vanished from the Sea of Abaco on April 4, 2026; the U.S. Coast Guard investigation remains open.Lady K SailingHe Solo Sails a 39 Footer!A solo sailor refits a 2007 Jeanneau Sun Odyssey 39, replacing keel bolts and upgrading electrical systems.Lady K SailingCheap Sailboats: The Dream, The Deal, and The DisasterDeck core rot and loose keel bolts are the two deal-killers in sub-$15,000 sailboats.Lady K SailingWhy You Should Start a YouTube Channel NowA 50,000-subscriber sailing channel typically generates $5,000 monthly through a split of ad revenue and Patreon support.Lady K Sailing

What they go for

Market signal

Where the fleet has seen this model for sale, and the asking prices that came with it.

1seen sold
1channel looked into buying
$1,000Median asking

From the fleet's own footage — our observed signal, not broker listings.

The record

Full specifications

The complete reference set — tap any figure to switch between metric and imperial.

Dimensions
Weights
Ballast / displacement
27.5%
Rig & sail area
Rig
Masthead Sloop
Ratios
SA / displacement
16.2
Displacement / length
195.3
Comfort ratio
15.2
Capsize screening
2.15
Hull speed
5.8 kn
Pounds / inch immersion
526
Hull
Hull type
Swing Keel
Construction
Fiberglass
Production
Years built
1975–1978
Designer
Halsey C. Herreshoff
Builder
Chrysler Marine

Boats like this, on the water

More boats like her, on the water

Comparable boats the fleet has on camera: same type, within a quarter of her length. Open the boat, or watch the video — a timestamp means she only appears in passing.

O'day 23-1 (Lift Top)7.01 mSame hull family0.3 m longerA popular C. Raymond Hunt-designed masthead sloop featuring a unique lift-top coach roof for added cabin headroom
Living on a Sailboat Doesn’t Have to Mean the End of Your Professional Life | #SAL #3583:10from Hashtag Sal
Cal Boats 247.43 mSame hull family0.7 m longerThe inaugural Jensen Marine Cal model, this fractional keel-centerboard sloop was built for shoal-water versatility
Aladino Sails The Pacific Alone.2:08from Sailing Magic Carpet
O'day 23-26.93 mSame hull family0.2 m longerA masthead keel-centerboard sloop produced in Brazil and the U.S. for over a decade as a popular coastal cruiser
Crazy Old Sailor #35 - Sailor who circumnavigated the Atlantic - Cribe - Europe - Crazy Old Man5:24from crazy old man
Hunter Marine 226.78 mSame hull familyNear-identical lengthA masthead-rigged trailerable cruiser with a keel-centerboard configuration for flexible draft and coastal access
What Happened to Hunter Sailboats? The History Most People Don't Know.from All About Sailing
O'day 205.97 mSame hull family0.7 m shorterA masthead sloop with a keel-centerboard configuration, offering a stable 5.57-knot hull speed for coastal cruising
The Romance of Sailing, Dan and Hadley Tell All! | Sailing Balachandra E054:49from Sailing Balachandra
O'day 257.57 mSame hull family0.9 m longerA successful decade-long production run defines this 25-foot masthead sloop, built with a versatile keel-centerboard
What if your office was a sailboat? | #SAL #3252:50from Hashtag Sal

The family

Related models

The designs closest to hers — usually the rest of the builder's range, sometimes the same hull sold under another name.

Chrysler Marine 20A Halsey C. Herreshoff-designed swing-keel sloop with a light 998kg displacement for easy trailering and shoal accessChrysler Marine 26A trailerable masthead sloop later produced by TMI as the C-26 and T-26 Courser with an optional fixed fin keelChrysler Marine 30 (CY 30)A 9.1-metre fractional sloop with a 44% ballast ratio, later produced by Texas Marine International as the TMI 30Chrysler Marine 27A masthead sloop with a 1.49-metre draft and a 48% ballast ratio, designed by Charles Morgan Jr. for stable cruisingTmi 26Masthead Sloop · 7.91 m
